aserati 4.7L V8 front engine bay central power distribution station and high-amperage battery pre-fuse block assembly

📌 Automotive Part Details

• Condition: Used (Good Functional Condition / Factory Quality Tested)

• Part Name: Engine Bay Central Fuse Box Module with Integrated High-Amperage Battery Terminal Distribution Block, Harness & Dual Actuator Motors

• Compatible with: * Maserati GranTurismo (M147): 4.7L V8 / S / MC Sport Line / MC Stradale models

  • Maserati GranCabrio (M147): 4.7L V8 / Sport / MC versions

  • Maserati Quattroporte V (M139): 4.7L V8 S / Sport GT S variants

• Model Years: 2008 – 2019 (For 4.7L V8 naturally aspirated Ferrari-derived engine platforms)

🔍 Part Identification

• Brand/Type: Genuine Maserati OEM Modular Power Distribution Assembly

• Assembly Validation Label: PN: 228543 / TEST OK

• Dual Rail Base Ref Stamp: 9270355 01 (ROTA910113 Tracking Architecture)

• Production Code Stamp: J51620 / 151219

• Dual Rail Tracking Serial: 00977 & 00978

• Production: Made in Germany / EU

📝 Item Description

Genuine Maserati 4.7L V8 front engine bay central power distribution station and high-amperage battery pre-fuse block assembly. This heavy-duty interlocking electrical network serves as the primary voltage protection gateway for the high-performance 4.7L powertrain, guarding the main starter motor, alternator, and body control networks. All composite plastic module covers are completely un-melted, the threaded brass terminal posts are clean and free of stripping, and all inner electrical connector pins are pristine and free of rust.

⚠️ Condition & Fitment Notes

• Condition Note: Comprehensive, high-grade salvaged engine-room power management setup. Fully pre-loaded with original high-capacity colored blade fuses (including 20A, 30A, 40A, 50A heavy-duty links) and high-current relays. Includes the heavy insulated main battery positive/negative leads, multi-plug green/blue coupling sockets, and accompanying auxiliary cylindrical actuator motors. Features factory quality control label PN: 228543 TEST OK.

• Ideal For: Replacing a water-damaged, burnt, or shorted engine bay fuse box causing total power crank failure, battery parasitic draw, or persistent powertrain relay communication codes.

• Important Note: Direct original mechanical swap for 4.7L spec engine rooms. Please cross-reference the side pin configurations and part numbers before ordering to ensure a perfect match for your vehicle's optional electronics.

🛡️ Warranty

• Warranty: 1-month replacement warranty covering main busbar power continuity, relay response logic, and fuse slot electronic faults.
